Set up and test-sewn on your material

SEWPRO
Double needleSKU 1141560 class

SEWPRO 1560N

2-Needle Walking Foot Lockstitch for Heavy Upholstery

A double needle walking foot for parallel seams on car seats, cushions and awnings, with a large vertical hook under each needle.

5.0 on Google from 10 reviews of SEWPRO

  • Stitch length8mm
  • Thread sizes46-138
  • Foot lift5/8"
  • Max speed2,000 RPM

Materials

  • Leather
  • Canvas
  • Vinyl
  • Upholstery fabric

Price

Quote on request

Quoted complete with table, servo motor and the attachments your job needs.

  • Set up, timed and test-sewn on your material before delivery
  • 1 year warranty on parts and workmanship
  • Delivered and installed in PA and nearby, freight nationwide
  • Phone and text support from the people who sold it

About the 1560N

The 1560N sews two rows at once with unison feed, which is how a trim shop sews French seams, double topstitch on bolsters and parallel rows on awnings and boat cushions. Each needle has its own vertical-axis large hook, so both rows lock the same way and bobbin changes are rare. The stitch goes to 8mm, the foot lifts 5/8 inch by knee, and the climbing device keeps the stitch even over a seam crossing.

It runs 46 to 138 thread through 135x17 needles at up to 2,000 RPM, with needle gauges from 3/16 to 1/2 inch available. A split needle bar for turning corners is an option.

Technical data: SEWPRO 1560N

Specifications

Specifications can change between production runs. Confirm the numbers that matter for your work when you order.

Machine Type2-Needle Walking Foot Unison-Feed Lockstitch
Max Sewing Speed2,000 RPM
Max Stitch Length8mm
Presser Foot Lift5/8" (By Knee)
Hook TypeVertical-Axis Large Hook
Needle System135×17 (Sizes 110-180)
Thread Sizes46-138
Extra FeaturesClimbing Device

Included in a SEWPRO quote

  • Head, table and stand
  • Servo motor, needle positioner where the head supports it
  • Feet, folders, clamps or guides for your product
  • A first box of Schmetz needles in the right system, point and size
  • Threaded, timed and sewn on your material before delivery
  • Delivery and installation in PA and nearby, freight elsewhere
  • 1 year warranty, phone support for the life of the machine
Schmetz

Authorized Schmetz dealer

Needles at dealer prices

This machine takes Schmetz 135×17, sizes 110 to 180. We stock it in round and leather points, by the box of 100 or the 10-pack, and the first box goes out with the machine.

Features

What is on the machine

  • Dual Needle CapabilityPerfect for strong parallel seam construction.
  • Walking Foot with Unison FeedSmooth feeding over multiple heavy layers.
  • Vertical-Axis Large HookEfficient thread handling for heavy-duty sewing.
  • Climbing DeviceMaintains stitch quality over thick joins and seams.
  • Designed for Heavy MaterialsHandles upholstery, vinyl, leather, and canvas.

Applications

What gets sewn on the 1560N

  • Automotive seat and interior upholstery
  • Marine seating and awnings
  • Heavy furniture upholstery
  • Canvas products and covers
  • Leather goods requiring parallel stitching

Compare

1560N against the alternatives

The models we would put next to it on the phone, and why.

ModelSEWPRO 1560NThis machineSEWPRO 1560N-72-Needle Walking Foot Lockstitch with Full AutomationSEWPRO 1760Post-Bed Double Needle Unison Feed Lockstitch MachineSEWPRO 8BL-20-220" Long-Arm Extra Heavy-Duty Double Needle Lockstitch Machine
Stitch length8mm8mm8mm10mm
Foot lift5/8" (By Knee)16mm (Auto, Requires Air)14mm (Pneumatic)20mm
Thread sizes46-13846-13846-138138-277
Needle system135×17 (Sizes 110-180)135×17 (Sizes 110-180)135×17 (Sizes 110-160)794 (Sizes 160-250)
Max speed2,000 RPM2,000 RPM1,800 SPM1200 RPM
HookVertical-Axis Large HookVertical-Axis Large HookLarge Vertical-Axis Rotary HooksVertical-Axis with Extra Large Bobbins
Arm / post / fieldOn requestOn request7"20"

Questions about the 1560N

Which gauge?

1/4 inch for most automotive and marine French seams, 3/8 or 1/2 for decorative rows on furniture. Send a sample seam and we match it.

1560N or 1560N-7?

The N-7 adds an automatic air foot lift and an under-bed trimmer. For a production seat line it pays; for a general upholstery shop the manual N is the better value.

Request a quote

SEWPRO 1560N

Tell us the material, how thick the stack gets, the thread you run and what you make. We will confirm the 1560N fits or point you to the model that does, then quote it complete with a delivery date.

SEWPRO 1560N

2-Needle Walking Foot Lockstitch for Heavy Upholstery

(717) 940-0129Monday to Friday, 7am to 5pm. Showroom visits by appointment.

Request concerns the SEWPRO 1560N. Tell us what you sew and we will confirm it is the right machine, quote it complete with table and servo motor, and give you a delivery date.

Answered within one business day. No mailing list.

Call TextGet a quote
