Set up and test-sewn on your material

SEWPRO
Flatbed walking footSKU 1361508 class

SEWPRO 1508NH

Unison-Feed Lockstitch for Extra Heavy-Weight Materials

The extra heavy version of the standard walking foot: vertical-axis large hook, 10mm stitch and room for a 190 needle.

5.0 on Google from 10 reviews of SEWPRO

  • Stitch length10mm
  • Thread sizes46-138
  • Foot lift5/8"
  • Max speed2,000 RPM

Materials

  • Extra-thick materials

Price

Quote on request

Quoted complete with table, servo motor and the attachments your job needs.

  • Set up, timed and test-sewn on your material before delivery
  • 1 year warranty on parts and workmanship
  • Delivered and installed in PA and nearby, freight nationwide
  • Phone and text support from the people who sold it

About the 1508NH

The 1508NH is what you buy when the 1541S is almost enough. It is the same kind of machine, a single needle compound feed flatbed, but built on the 1508 platform with a vertical-axis large hook, a longer needle bar stroke and a bigger 5/8 inch knee lift. The result is a machine that will run 138 thread all day and 207 when you need it, through stacks of leather, canvas or webbing that make a lighter machine skip.

The H in the model stands for heavy. The 1508N without the H is a medium-heavy machine; the NH uses the longer 190 needle system in the heavy configuration so the needle has more shank in the bar and deflects less in dense material. If you sew webbing, saddle pads, tarps, or leather over 8 oz, this is the flatbed to start with.

Technical data: SEWPRO 1508NH

Specifications

Specifications can change between production runs. Confirm the numbers that matter for your work when you order.

Machine Type1-Needle, Unison-Feed, Lockstitch
ApplicationExtra Heavy-Weight Materials
Max Sewing Speed2,000 RPM
Max Stitch Length10mm
Presser Foot Lift5/8" (by Knee)
Needle System135×17 (Nm160) Sizes Nm125-Nm180
Thread Sizes46-138
Hook TypeVertical-Axis Large Hook
Alternating foot stroke2.5 to 6.5mm

Included in a SEWPRO quote

  • Head, table and stand
  • Servo motor, needle positioner where the head supports it
  • Feet, folders, clamps or guides for your product
  • A first box of Schmetz needles in the right system, point and size
  • Threaded, timed and sewn on your material before delivery
  • Delivery and installation in PA and nearby, freight elsewhere
  • 1 year warranty, phone support for the life of the machine
Schmetz

Authorized Schmetz dealer

Needles at dealer prices

This machine takes Schmetz 135×17 (Nm160). We stock it in round and leather points, by the box of 100 or the 10-pack, and the first box goes out with the machine.

Features

What is on the machine

  • Unison-Feed SystemTriple feed for perfect stitch quality on heavy materials.
  • Vertical-Axis Large HookFewer bobbin changes for long production runs.
  • 10mm Stitch LengthIdeal for heavy-duty seams.
  • High Foot Lift (5/8")Easily handles thick, layered fabrics.
  • Designed for Extra Heavy-Weight ApplicationsPerfect for leather, canvas, and industrial textiles.

Applications

What gets sewn on the 1508NH

The SEWPRO 1508NH is a 1-needle unison-feed lockstitch machine designed to handle extra heavy-weight materials such as leather, canvas, and multi-layer technical fabrics. Featuring a vertical-axis large hook, it provides extended thread capacity and stable stitching even at maximum speed.

Its unison-feed system, combining needle feed, walking foot, and bottom feed, ensures smooth, even fabric movement without shifting, making it ideal for demanding industrial applications where precision and durability are essential.

Compare

1508NH against the alternatives

The models we would put next to it on the phone, and why.

ModelSEWPRO 1508NHThis machineSEWPRO 1541SHeavy-Duty Walking Foot Lockstitch Sewing MachineSEWPRO 1508L-18Long-Arm Walking Foot Lockstitch MachineSEWPRO 204-420Barrel Shuttle Lockstitch for Extra Heavy-Weight Sewing
Stitch length10mm9mm9mm12mm
Foot lift5/8" (by Knee)16mm5/8" (Air, Requires Compressed Air)24mm
Thread sizes46-13846-13846-138138-415
Needle system135×17 (Nm160) Sizes Nm125-Nm180135×17 (Sizes 110-180)135×17 (Sizes 110-180)794 (Sizes 160-230)
Max speed2,000 RPM2,500 RPM1800 RPM (Material Dependent)600 RPM
HookVertical-Axis Large HookHorizontal-Axis Full-Rotary Double-Capacity Hook (M size bobbin)Vertical-Axis Large HookOn request
Arm / post / fieldOn requestOn request18"16"

Questions about the 1508NH

Can it run 207 thread?

Yes, with a size 23 or 24 needle. 277 is at the edge: it will sew, but a 441 class or the 204-420 does it without strain.

Is it faster than the 1541S?

No. It tops out at 2,000 stitches per minute against 2,500. Nobody sews heavy material at those speeds anyway.

What is the difference between the NH and the 1508L-18?

The L-18 is the same head on an 18 inch arm. Same hook, same stitch, more room under the arm for seat covers and biminis.

Request a quote

SEWPRO 1508NH

Tell us the material, how thick the stack gets, the thread you run and what you make. We will confirm the 1508NH fits or point you to the model that does, then quote it complete with a delivery date.

SEWPRO 1508NH

Unison-Feed Lockstitch for Extra Heavy-Weight Materials

(717) 940-0129Monday to Friday, 7am to 5pm. Showroom visits by appointment.

Request concerns the SEWPRO 1508NH. Tell us what you sew and we will confirm it is the right machine, quote it complete with table and servo motor, and give you a delivery date.

Answered within one business day. No mailing list.

Call TextGet a quote
