Zig-zagSKU 145204 class, zig-zag, top feed

SEWPRO 204ZTS

Heavy-duty walking foot zig-zag with large hook

An extra heavy zig-zag with a 12mm bite, top feed and a barrel shuttle, for leather, canvas, tarps and sails.

5.0 on Google from 10 reviews of SEWPRO

Stitch length10mm
Zig-zag width12mm
Thread sizes138 to 346
Max speed800 stitches per minute

Materials

Canvas
Leather
Sails
Tarpaulins
Upholstery

Price

Quote on request

Quoted complete with table, servo motor and the attachments your job needs.

Request a quote (717) 940-0129

Set up, timed and test-sewn on your material before delivery
1 year warranty on parts and workmanship
Delivered and installed in PA and nearby, freight nationwide
Phone and text support from the people who sold it

About the 204ZTS

The 204ZTS is the widest-bite heavy zig-zag in our range. Twelve millimeters of zig-zag, a 10mm straight stitch, a barrel shuttle for thread from 138 to 346, a top feed that works with the drop feed on difficult materials, and reverse. The 794 needle runs from 160 to 230 and the top speed is 800 RPM.

It is for sail lofts, tarp and tent makers, leather shops that zig-zag elastic and gussets, and boot repairers. The barrel shuttle is the reason it holds heavy thread without tension trouble.

Technical data: SEWPRO 204ZTS

Specifications

Specifications can change between production runs. Confirm the numbers that matter for your work when you order.

Machine Type	Extra heavy-duty zig-zag lockstitch, top and drop feed
Max Sewing Speed	800 stitches per minute
Max Stitch Length	10mm
Zig-Zag Width	12mm
Hook Type	Barrel shuttle
Needle System	794, sizes 160 to 230
Thread Sizes	138 to 346
Extra Features	Reverse stitch

Included in a SEWPRO quote

Head, table and stand
Servo motor, needle positioner where the head supports it
Feet, folders, clamps or guides for your product
A first box of Schmetz needles in the right system, point and size
Threaded, timed and sewn on your material before delivery
Delivery and installation in PA and nearby, freight elsewhere
1 year warranty, phone support for the life of the machine

Authorized Schmetz dealer

Needles at dealer prices

This machine takes Schmetz 794, sizes 160 to 230. We stock it in round and leather points, by the box of 100 or the 10-pack, and the first box goes out with the machine.

Needles and prices (717) 940-0129

Industries

Features

What is on the machine

Top feed and drop feed for superior material handling
Maximum sewing speed800 SPM
Maximum stitch length10mm
Zig-zag width12mm
Needle type794 (sizes 160-230)
Thread size138-346

Applications

What gets sewn on the 204ZTS

Leatherworking
Canvas and tarp fabrication
Upholstery
Sailmaking
Shoe and boot repair
Industrial and heavy-duty sewing projects

Compare

204ZTS against the alternatives

The models we would put next to it on the phone, and why.

SEWPRO 204-104A
Same class with top and bottom feed.
SEWPRO 266
Sailmaker's heavy zig-zag.
SEWPRO 2153L30
30 inch long arm walking foot zig-zag.

Model	SEWPRO 204ZTSThis machine	SEWPRO 204-104AWalking foot zig-zag for sails, upholstery and leather	SEWPRO 266Heavy-duty walking foot zig-zag sewing machine	SEWPRO 2153L3030" long arm walking foot zig-zag machine
Stitch length	10mm	10mm	On request	On request
Foot lift	On request	12mm	On request	On request
Thread sizes	138 to 346	138 to 346	138 to 346	On request
Needle system	794, sizes 160 to 230	794, sizes 160 to 230	794, sizes 160 to 230	135x17
Max speed	800 stitches per minute	800 stitches per minute	On request	On request
Hook	Barrel shuttle	Barrel shuttle	Barrel shuttle	On request
Arm / post / field	On request	On request	On request	30 inches

Questions about the 204ZTS

Can it sew straight stitch too?

Yes. Set the width to zero and it is a heavy straight stitch machine with a barrel shuttle.

Request a quote

SEWPRO 204ZTS

Tell us the material, how thick the stack gets, the thread you run and what you make. We will confirm the 204ZTS fits or point you to the model that does, then quote it complete with a delivery date.
